When was a kitchen refrigerator receptacle outlet first required to be GFCI-protected?

Wednesday, June 19, 2019

The change came with the 2014 edition of the National Electrical Code (NEC), and it does not actually state that a refrigerator in the kitchen must be GFCI-protected. What it says is that any receptacle within 6 feet of the top edge of a sink bowl must have GFCI-protection. So many refrigerator receptacle outlets are going to fall within that 6-foot radius of the kitchen sink edge, but some will not.

Previously all kitchen counter receptacles were required to be GFCI, but other receptacle outlets around the kitchen were exempted. There was a requirement since the 1993 NEC for receptacles outlets within 6 feet of a laundry, utility, or wet bar sink to be GFCI, but it was expanded to include all sinks in the house with 2014 NEC.

    As the NEC has updated with a new edition every three years, the locations required have been expanded or tweaked with almost every cycle since then. For a complete listing of each currently required location for GFCI-protection and when it was instituted, see our blog post When were GFCI receptacle outlets first required?


    But, while the year that the NEC added a new location requirement is easy to define, each local juridiction’s building codes don’t necessarily adopt the latest edition of the NEC immediately. The state of Florida, for example, did not make the 2011 NEC effective until mid-2015. Other jurisdictions have sometimes waited even longer to adopt a newer NEC edition and, to complicate things further, they might make amendments that exclude parts of the newest requirements. So the year when the NEC first required GFCI-protection for a new receptacle location can be several years before your local building department adopted that edition of the code and began enforcing it.

    One last note: GFCI-protection can be provided by a GFCI receptacle (one receptacle will protect others downstream in the circuit, which should be marked as GFCI protected), a GFCI circuit breaker in the electric panel, or a GFCI dead front (often used for indoor spa tubs, essentially a GFCI receptacle without the slots to plug in a cord, usually located in bathroom or next to electric panel).

• • • • • • • • • • • • • • • • • • • • • • • • • •

Here’s links to a collection of our other blog posts about AFCI and GFCI RECEPTACLES AND CIRCUIT BREAKERS:

Does a septic pump or sump pump require a GFCI-receptacle?

 • What is the difference between what trips a GFCI (ground fault) receptacle and a circuit breaker?

Are Ground Fault Circuit Interrupters (GFCIs) really necessary and worth the trouble?

What is the code requirement for GFCI protection for receptacles near a wet bar sink?

When was GFCI-protection for kitchen dishwasher receptacle outlet first required?

When did arc fault circuit interrupter (AFCI) breakers first become required?

Does a washing machine receptacle outlet require GFCI protection?

My spa tub stopped working. What's wrong?

How do I identify a combination AFCI (CAFCI) circuit breaker?

What does "listed and labeled" mean for an electrical component?

What electrical hazards does a Ground Fault Circuit Interrupter (GFCI) NOT protect against?

What is the difference between GFCI and AFCI circuit breakers?

Where are GFCI receptacle outlets required?

When were GFCI receptacle outlets first required?

What happens when you press the "TEST" button on a circuit breaker in an electric panel?

What is the difference between the electric service to a mobile home and a site built home?

Why is there a wall switch next to the furnace or indoor unit of the air conditioner in the garage?

What is a Dual Function Circuit Interrupter (DFCI)?

How I can tell if a receptacle outlet is tamper resistant?

What is the difference between a Combination Arc Fault Circuit Interrupter (CAFCI) and an Arc Fault Circuit Interrupter (AFCI) circuit breaker?

What is the difference between "grounded" and "grounding" electrical conductors?

What does it mean when a wire is "overstripped" at a circuit breaker?

Why is there a GFCI breaker in the electric panel for the bathroom shower light and exhaust fan?

What is the switch on the wall with two pushbuttons?

How far apart should kitchen counter receptacles be spaced?

How far above a kitchen countertop do electrical outlets have to be?

How is it possible to provide both GFCI (Ground Fault Circuit Interrupter) and CAFCI (Combination Arc Fault Circuit Interrupter) protection for kitchen and laundry circuits?

My bathroom electric receptacle/outlet is dead and there are no tripped breakers in the electric panel. What's wrong?

My GFCI reset button is hard to push and won't reset. What's wrong?

Why do some breakers in my electric panel have a "TEST" button on them?

    Visit our AFCI AND GFCI page for other related blog posts on this subject, or go to the INDEX for a complete listing of all our articles.
