Pipe Size Based On Fixture Units
We don’t know of any specific minimum in the International Building Code (IRC) or Florida Building Code (FBC), but the sizing of water distribution pipes is based on a combination of “fixture units,” which is a number assigned to different types of plumbing fixtures according to their likely water usage, and the length of piping in the system. To complicate things further, the calculation also requires an allowance for the friction in the pipes based on type of pipe and number of elbows.
But, on average, a 1/2” distribution pipe is only good for about 3 fixture units, while a 3/4” pipe is rated at approximately 10 fixture units. The hot water fixture rating of a bathroom is 1.5 fixture units, and a kitchen with sink and dishwasher adds 1.9 fixture units That’s 3.4 already, and we haven’t even added a laundry at 1.8 fixture units. So a 3/4” inlet pipe would be the minimum for most homes.
Just to be sure, we checked with our plumber, James Freeman, of J.W. Freeman Plumbing in Gainesville. “You need to know how many fixtures are being fed by the water heater, and then use the tables in Appendix E of the Florida Plumbing Code,” according to James. “Most homes will need 3/4”. Some of the older houses in town, though, piped the entire hot water system in 1/2”, to get the hot water faster and cut down on waste.”
• • • • • • • • • • • • • • • • • • • • • • • • • • • •
