How many receptacle outlets can you have on one circuit?

Friday, June 22, 2018

There is no limitation on the number of general purpose duplex receptacles you can have on a 15-amp or 20-amp circuit breaker. Too many outlets, however, increases the likelihood of overloading a circuit with connected appliances and lights. Plus, the long wire runs and number of wire connections of a circuit with dozens of receptacles can reduce the voltage serving the ones further down the line to below an acceptable level. A  common rule-of-thumb is a maximum of 10 receptacle outlets per circuit, and a minimum of one circuit per 500 square feet of floor area.

    The National Electrical Code [NEC 210.52(C)] requires a minimum of two 20-amp circuits for kitchen appliances, and the requirement has been in place since the 1959 edition of the NEC, but does not specify a maximum number of receptacles on each circuit.

    Also, see our blog post How far apart should kitchen counter receptacles be spaced?


• • • • • • • • • • • • • • • • • • • • • • • • • • • •
